Medium Modern Minimalist One-Wall Kitchen Cabinet Layout - PDF Drawing Set | 1094-KI
One-wall / inline kitchen layout, including RediiCabi PDF layout pages and shop drawing style cabinet/elevation details.
Drawing Specifications
- Drawing Code
- 1094-KI
- Room Type
- Kitchen
- Room Size
- Medium
- Overall Size
- 14.3 ft x 8.1 ft
- Ceiling Height
- 9 ft ceiling
- Room Area
- 116 sq ft
- Layout
- No island / peninsula
- Style
- Modern / Minimalist
- Detail Level
- Shop drawing style
- Pages
- 3 pages
- Wall / Elevations
- 2 elevations
- File Type
- Suitable For
- Kitchen renovation, new build, detached home, townhome, condo kitchen planning
Inside the Drawing Set
1094-KI · 3 pages · PDF
Plan, elevations & shop-ready details — drawn at architectural scale.
- Plan ViewA-100
- Elevation 1A-200
- Elevation 2A-201
- Specs Cabinet + AccessoriesA-300
- Appliances SpecsA-400
