1012-CCloset · Small
$49
Drawing 1026-CL
Medium Modern Minimalist Closet and Laundry Cabinet Layout - PDF Drawing Set | 1026-CL
Closet + laundry cabinet layout drawing set with RediiCabi PDF layout pages and shop drawing style details.
Drawing Specifications
- Drawing Code
- 1026-CL
- Room Type
- Closet
- Room Size
- Medium
- Overall Size
- 9.0 ft x 8.2 ft
- Ceiling Height
- 10 ft ceiling
- Room Area
- 74 sq ft
- Layout
- No island / peninsula
- Style
- Modern / Minimalist
- Detail Level
- Shop drawing style
- Pages
- 8 pages
- Wall / Elevations
- 7 elevations
- File Type
- Suitable For
- Closet + Laundry renovation, millwork planning, cabinet quote reference
Inside the Drawing Set
1026-CL · 8 pages · PDF
Plan, elevations & shop-ready details — drawn at architectural scale.
- Plan ViewA-100
- Elevation 1A-200
- Elevation 2A-201
- Elevation 3A-202
- Elevation 4A-203
- Elevation 5A-204
- Elevation 6A-205
- Elevation 7A-206
Need a Custom Drawing?
Tell us your room dimensions and style direction — our team can adapt 1026-CL or draw a new set tailored to your build.
