Small Modern Minimalist One-Wall Kitchen Cabinet Layout - PDF Drawing Set | 1024-KI
One-wall / inline kitchen layout, including RediiCabi PDF layout pages and shop drawing style cabinet/elevation details.
Drawing Specifications
- Drawing Code
- 1024-KI
- Room Type
- Kitchen
- Room Size
- Small
- Overall Size
- 9.2 ft x 2.5 ft
- Ceiling Height
- 8 ft ceiling
- Room Area
- 23 sq ft
- Layout
- No island / peninsula
- Style
- Modern / Minimalist
- Detail Level
- Shop drawing style
- Pages
- 2 pages
- Wall / Elevations
- 1 elevations
- File Type
- Suitable For
- Kitchen renovation, new build, detached home, townhome, condo kitchen planning
Inside the Drawing Set
1024-KI · 2 pages · PDF
Plan, elevations & shop-ready details — drawn at architectural scale.
- Plan ViewA-100
- Elevation 1A-200
- Specs Cabinet + AccessoriesA-300
- Appliances SpecsA-400
- Schedule & NotesA-500
Need a Custom Drawing?
Tell us your room dimensions and style direction — our team can adapt 1024-KI or draw a new set tailored to your build.
Request Custom Drawing →Related Drawings
